PeakTech^® 9040

Wireless Energy Meter-Set consisting of a transmitter & receiver

This newly developed energy cost meter can receive the electrical power of up to four transmitters. The device is counting the consumption continuously and through this weekly, monthly and annual consumption. So electrical loads can be monitored over a long period of time and energy intensive equipment will be identified.

The wireless 2.4 GHz receiver technology allows a wide range between transmitter and receiver from up to 100 meters, so that the user can install the receiver unit in the workplace, from where it can monitor and also switch the inputs by pressing a button. Additionally it allows the programming of automatic on and off switching states depending on the day and time.

The large 8cm LCD multi-line display simultaneously shows the on-, or off state, the current consumption, energy costs and the current time and date.

Optionally, the display can be switched by pressing a button to show the cost of electricity per hour, the voltage and current ratings or the CO ² emissions for energy consumers.

• Present-, Weekly-, Monthly-, Annual- consumption counter
• Wireless receiver with up to 100m range
• Large 8 cm multi-line display
• Four measurement channels on the receiver unit
• Channels switchable by receiver
• Day and Night tariff adjustable
• Time switching function for all four channels
• CO2 emission calculation in CO2/kg
• Receiver freestanding or wall mountable
• Safety: GS, EN 61010-1, CAT II 300 V
• Accessories: 1 x Transmitter, 1 x Receiver, Batteries, User manual
• Additional accessories: transmitter P 9040 TR
