PeakTech® 9021
THB 13,000.00
DVB-S/S2 Meter
The new PeakTech 9021 DVB-S2 meter is used for the signal search in satellite systems and offers a wide range of functions for the daily use during the installation or testing of TV systems.
Through the graphical user interface, all necessary functions such as the satellite search with related LNB configuration, alignment of the satellite system, the spectrum analyzer and the many media functions can easily be activated and used.
This model is used by the built-in HDMI port as a full replacement for a receiver and through the AV IN jack, it is also suitable for testing external sources such as AV surveillance cameras. The TV picture display also for HD channels enables precise evaluation of the received TV-stations.
Through these excellent technical properties, this device is suitable for everyday use of the electrician or television technician in the field.
- 90 mm (3.5 ") TFT color display with 320 x 240 pixels
- Live TV screen for displaying SD and HD channels
- DVB-S & S2 demodulation with QPSK / 8PSK
- Angle calculation to align the satellite-system
- Spectrum Analyzer function
- USALS alignment with DiSEqc
- Media Player and recording function
- HDMI, AV-In and USB Interface
- Removable Lithium-Ion battery with 2600mAh
- Accessories: AC adapter, Car charger adapter, AV cable, USB cable, Software for Windows XP/VISTA/7/8, Carrying case, User manual
- Additonal accessories: Battery pack 11,1 V/2600 mAh, model AKKU 7
| SATELLITE : | |
|---|---|
| Standard | DVB-S / DVB-S2 |
| Frequency range | 950 MHz-2150 MHz |
| LNB-control | 13/18 V, max. 400 mA.; 22 kHz |
| Signal Level | -65 dBm ~ -25 dBm |
| DiSEqC | Version 1.0 / 1.1 |
| Demodulator (DVB-S/DVB-S2) | QPSK, 8PSK |
| SYSTEM : | |
| Processor / SD-RAM / Flash | 450 MHz / 256 MByte / 16 MByte |
| MPEG 2 | MPEG-2MP@ML, MPEG-2MP@GHL> |
| MPEG 4 | MPEG-4 AVC/H264 HP@L4> |
| Resolution | HDMI1080P, 1080i.720P, 576P, 576I |
| GENERAL : | |
| Interface | 1 x USB 2.0, 1 x HDMI, 1 x AV-IN/OUT |
| Power Adapter | 100 ~ 240 V AC; 50/60 Hz Input ; 14V/3A DC Output ; 12 V Car Charger |
| Battery | 11.1 V; 2600 mAh |
| Dimensions (WxHxD) | 175 x 125 x 35 mm |
| Weight | 450 g |
| EAN-13 | 4250569403422 |
